Owner's manual

INSTALLATION & ASSEMBLY INSTRUCTIONS
Some assembly is required for your new air conditioner. Please read and follow these instructions carefully.
1. This air conditioner is designed to be installed in a
standard double-hung window with a window width
between 22” and 36” (559 mm - 914 mm).
2. The air con
ditioner can be installed without the
accordion panels to fit in a narrow window opening.
See the window dimensions.
3. The Lower Sash (the lower part of the window that
moves up and down) must allow for 13.25” of vertical
clearance when open. (See FIG. 1).
4. All supporting parts must be secured to firm wood,
masonry, or metal.
5. The electrical outlet must be within reach of the power
cord.
NOTE: Save the product packaging and installation instruc-
tions for future reference. Store the air conditioner in the
product box when not in use for an extended period of time.
FIG. 1
When handling the unit, be careful to avoid cuts from
the sharp metal edges and aluminum fins on the front
and rear coils.
22" to 3 6"
559mm to 914mm
13 1/4"
(337mm)
