Up Time The elapsed time that the unit has been running since the last reboot or power cycle.
Ethernet Port – details of the Ethernet port status can be viewed by clicking the details on the
right side of the screen. The actual screen is shown in Section C below. The Ethernet Port MAC
address is shown for diagnostics purposes, but has no effect on the Master unit to client
wireless connection.
RF Port – The RF Port MAC address is what is used by access control and thus must be
entered into the access control list at the Master unit.
State (RF Port) The link state has two values.
Green – An RF link has been established
Red – An RF link is NOT established.
Clicking on the details button on the Ethernet port and RF port will show the following screen.
