User Manual

Bandwidth Allows selection of the bandwidth (BW), in MHz, of the RF network. The standard

channel is 10 MHz and there are two channels with 20MHz bandwidth.

Both Master and Slave units must be configured with the same Bandwidth setting.

Frequency Allows selection of the center frequency of the RF link, based on the model

purchased, region of operation and operating bandwidth. The Frequency setting is available on

the Master unit only. The slave unit will follow that of the Master unit.

A sample frequency list for the US FCC ITS band, is as follows:

Channel Number and BW Frequency Center Application Product

# 172 – 10MHz 5860 MHz XL5910 and XL5930

# 174 – 10MHz 5870 MHz XL5910 and XL5930

# 176 – 10MHz 5880 MHz XL5910 and XL5930

# 178 – 10MHz 5890 MHz XL5910 and XL5930

# 180 – 10MHz 5900 MHz XL5930 Only

# 182 – 10MHz 5910 MHz XL5930 Only

# 184 – 10MHz 5920 MHz XL5910 and XL5930

# 175 – 20MHz 5875 MHz XL5930 Only

# 181 – 20MHz 5905 MHz XL5930 Only

NOTE – Due to the FCC EIRP regulations, XL5910 PTP kits with 23 dBi antenna

cannot be used in certain channels as indicated above (#180, 182, 175, and 181).

Link Distance Should be set to the link distance, rounded up to the nearest mile or km. This

parameter is used to optimize the performance across long distance links, accounting for the

time of flight of packets from one side to the other.

RF Network Name The wireless network name assigned to this PTP kit only.
