User Manual

The unit with properly installed feedthrough appears as follows:

NOTE - Removal of the RJ45 plug from the radio requires a tool such as a thin

screwdriver, or opened paperclip. Care must be taken not to damage the

Feedthrough Body or RJ45 plug.

NOTE - The total combined length of the Ethernet cables between the radio and

your network access device (hub/switch/PC) must not exceed 300 feet.

NOTE - Once mounted in a permanent location, additional weatherproofing tape

(included) should be applied around the assembled fitting to further enhance

durability.

5.3 Mounting Bracket and Tools

The following figure shows all components of the mounting kit.
