User Manual

NOTE -Using a file transfer to a shared volume or an FTP session on a typical

Windows/Intel machine is not adequate to accurately measure throughput.

NOTE - Units bench tested in an indoor configuration should not be

expected to deliver full rated throughput. Benchmarking is typically

performed after a system is deployed.

WARNING – When it is not in use, the GPS port of the GPS-ready Master unit

must be sealed to prevent water intrusion. The port is factory configured with a

sealing pin. Please leave it in place until you are ready to connect to a GPS

controller.

5. Physical Installation

5.1 Introduction

Your SkyWay radio is designed with a mounting system with two degrees of freedom. The radio

can be mast, tower, pole or wall mounted using the appropriate hardware. After determining the

best location for your radio, installation can begin.

To mount a SkyWay-XL100t radio unit, both the mast mounting kit and Ethernet cable

feedthrough need to be correctly assembled. The recommended approach consists of 3 or 4

steps, detailed in the following sections:

• Ethernet cable / feedthrough assembly

• Bracket preparation

• Mounting

• Antenna mounting (for connectorized units, only)

With the exception of the CAT5 cable, all parts and hardware described in the following sections

are included with your SkyWay radio.
