User's Manual

22. Diagnostics

For diagnostics, navigate to Diagnostics => Time/Ping menu to view the

following:

The ping tool can be used to isolate an issue to the wireless link only, not

involving other network elements such as switches and host computers. You

can ping the remote unit from the unit you are accessing via the user interface.

Destination Addr: The IP address of the device to be pinged.

Packet Size: The size of the ping packets to be sent (in bytes).

Packet Count: The number of packets to be sent to the destination IP address.

Click on the Start button to initiate the ping session. Click Stop to terminate it.

Appendix A: Factory Configuration

WIRELESS

Radio Spectrum bandwidth 20 MHz

Frequency (Master-only) Product / Region Specific

RF Power 17 dBm

Modulation QAM16-1/2

Streams 1

Distance 16 miles

RF Network Name Name_1

Security Open (AES and Radius disabled)

Access Control List (ACL) Enabled

LAN

IP Address (Master / Slave) 192.168.1.200 / 192.168.1.100

IP Mask 255.255.255.0

IP Gateway 192.168.1.1

Ethernet Port Auto
