User's Guide

Configuring the Ports
73
RF Diagnostics Port
There are two diagnostic ports, the RF-DLC Base Diagnostic port and the RF-DLC
Sub Diagnostic port. Both of these use the control interface of the RF driver to perform
RF diagnostics.
1.2.3.2 RF Diagnostic Port Configuration
The following table lists the field name, the MIB name, and field options with the
default setting in bold:
Field Name MIB
Settings (default in
bold)
Port Number [swRFDiagPortIndex] 3
The RF port number.
Configuration Status [swRFDiagPortConfigSta-
tus]
• On-line
• Off-line
Determines if this port is initialized upon reset. Off-line prevents the port from being
initialized upon reset.
Port Type [swRFDiagPortPorttype] RF Sub Diagnostics Port
RF Sub Diagnostic port.
Max Buffers [swRFDiagPortMax-
Buffers]
800
The number of message buffers.
Transmit Buffers [swRFDiagPortTransDesc] 240
The number of transmit buffers.
1.2.3.2 RF Diagnostic Port Configuration Record 1 of 3
Port Number :3
Configuration Status :On-line
Port Type :RF-DLC SUB Diagnostic Port
Max Buffers :800
Transmit Buffers :240
Receive Buffers :180
Maximum Frame Size :1549
Record Type :Valid
\ - return to menu . - commands TAB - next available field ENTER - edit
