User's Guide

60
Trap Community Name
The trap community name of the SkyWay agent. If you set Enable Traps to Yes and
the NMS expects SNMP traps with community name, this field must match com-
munity name configured on the NMS.
Enable Traps •
••
•No
NoNo
No
•Yes
Set to Yes to enable SkyWay to log and transmit SNMP traps. Set a Trap Destination
Address to send traps to the NMS.
Authentication Traps No
Set to Yes to cause a trap when an SNMP packet is received with an incorrect com-
munity name.
NMS IP Address 1
The IP address of the first NMS. This address setting is optional when using a NMS.
This provides an extra layer of security by forcing the IP addresses to match.
NMS IP Address 2
The IP address of the second Network Management station. This address setting is
optional when using a NMS. This provides an extra layer of security by forcing the
IP addresses to match.
Trap Destination IP
Address 1
The IP address of the first NMS to receive SkyWay SNMP traps. Enable Traps must
be set to Yes.
Trap Destination IP
Address 2
The IP address of the second NMS to receive SkyWay SNMP traps. Enable Traps
must be set to Yes.
Field Name
Settings (default in
bold)
