User's Guide

Setting System Configuration Parameters
59
Setting System Configuration Parameters
SkyWay’s system parameters fall into four main areas:
•Network Management Security
• Network Management System
• User Access
• General Parameters
Setting Network Management Security Parameters
Use screen 1.1.1 to set up security parameters for network management. To access
this screen, you must have an access level of Super. This screen is not accessible via
SNMP.
1.1.1 Network Management Security Configuration
The following table lists the field name and settings (there are no MIB OIDs for this
screen):
Field Name
Settings (default in
bold)
Read Community Name public
The read-only community name of the SkyWay agent. Must match community
name configured on the Network Management Station (NMS).
Write Community Name
The read-write community name of the SkyWay agent. Must match community
name configured on the NMS.
1.1.1. Network Management Security Configuration
Network Management Configuration:
---------------------------------
Read Community Name : public
Write Community Name :
Trap Community Name :
Enable Traps : No
Authentication Traps : No
NMS IP Address 1 : 000.000.000.000
NMS IP Address 2 : 000.000.000.000
Trap Destination IP Address 1 : 000.000.000.000
Trap Destination IP Address 2 : 000.000.000.000
\ - return to menu . - commands TAB - next available field ENTER - edit
