Step 4: Starting the
Bench Test
The two SkyWay units will now transmit information back and forth to test wireless
performance.
1
2
4
3
4.1 RF Base Radio Test
* Note - diagnostic driver must be installed *
RF Port Number 3
Test Timeout (NSL List) Milliseconds
Test To Run Single Frame Ping Pong Mode
Number of Frames or Bursts, 1 to 65535 or 0 for continuous : 0
Frame Length or Maximum Burst Size, 3 - 3200 bytes : 1530
Set up the Base Station Test:
Go to SkyWay1 (the base
station).
Type
QN to access this
screen
Test to Run = Single Frame
Ping Pong Mode
Test Timeout = depends on
the bandwidth:
 36 ms for 2 Mbs
 12 ms for 5.5 Mbs
 9 ms for 11 Mbs
Type
Kª to write the changes
Set up the Sub Station Test:
Go to SkyWay2 (the sub
station).
Type
QO to access this
screen
Test to Run = Single Frame
Ping Pong Mode
Type
Kª to write the changes
4.2 RF Sub Radio Test
* Note - diagnostic driver must be installed *
RF Port Number 3
Test to Run Single Frame Ping Pong Mode
Monitor the test on the Sub:
You are still at SkyWay2 (sub).
Type
OOQ to access this
screen
Type
Kw to clear the
statistics
Type
Kj to enter monitor
mode
5
2.2.4 RF Port Status
Port Number 3
Port Type Sub Port Diagnostic
Port Status On-line
RF data rate 2 Mbps
RF Channal 2468 Mhz
Bytes IN 0 OUT 0
Frames IN 0 OUT 0
Discards IN 0 OUT 0
Digital Phase Lock Loop
Frame Length Violation
Non Octet Aligned Frame
Abort Sequence
CRC Error
Overrun
Carrier Detect Lost
Underrun
CTS Lost
Monitor the test on the Base:
Go to SkyWay1 (the base
station)
Repeat Step 5 - the Port Type is
Base Port Diag
6
7
Check the results:
Wait at least 30 seconds for an
accurate reading
Total the sum of the errors in
the errors column. The sum
should be less than 1% of the
total number of frames
received (IN).
8
9
Terminate the test:
Go to screen 4.1.2 and change
Test to Run = Terminate Test
Type
Kt to write the change
