Step Two:
Preparing the
Computer
Workstation for the
Bench Test
Use the following steps to set up the administration console that you will use to moni-
tor and configure the test. The following shows an example using a PC with Hyper-
term set for VT-100 terminal emulation.
1
2
3
4
Start a Hyperterminal Session:
Under Windows, click Start,
Accessories, Hyperterminal.
Set up COM 1:
In Connection Description:
Select an icon
Enter a name - for example:
COM1 - SkyWay 1;
COM2 - SkyWay 2
Connect to COM1:
In Connect To Dialog, at
Connect Using:
Select COM1
Set up COM1 properties:
In COM1 Properties: choose
these port settings:
 BPS - 115200
 Data bits - 8
 Parity - none
 Stop bit - 1
 Flow control - none
Set VT-100 Emulation:
In Hyperterminal, click File--
Properties--settings tab
 Choose VT-100 Emulation
 Click ASCII button
 Uncheck Wrap lines.... box.
5
6
DONE
Repeat Steps 1 - 5 for the
second SkyWay:
lf you are using only one PC, set
up COM 2 port on the PC.
If you are using two terminals or
PCs, set up the other terminal or
COM 1 on the other PC.
