1.2.1.1 Serial Port Configuration
Field Name MIB Default Setting
Port Number [swSerialPortIndex] 1
The serial port number is 1.
Configuration Status [swSerialPortConfigSta-
tus]
On-line
Whether this port configuration initializes upon reset. On-line means the port
comes up as a serial port when the unit is reset; Off-line means the port does not
initialize upon reset.
Buffers [swSerialPortMaxBuffers] 80
Serial port buffers.
Transmit Buffers [swSerialPortTransDesc] 16
Serial port transmit buffers.
Receive Buffers [swSerialPortRecvDesc] 16
Serial port receive buffers.
Maximum Frame Size [swSerialPortMaxFrame-
Size]
512
Largest frame that can be transmitted vial the serial port
1.2.1.1 Serial Port Configuration
Port Number : 1
Configuration Status : On-line
Buffers : 80
Transmit Buffers : 12
Receive Buffers : 12
Maximum Frame Size : 512
\ - return to menu . - commands TAB - next available field ENTER - edit
