Appendix K:
Appendix K: Appendix K:
Appendix K:
Skyway Antennas
Skyway AntennasSkyway Antennas
Skyway Antennas
A good wireless connection depends on the antenna you choose and mount.
This chapter contains information about the following antennas:
7002301: 6 dBi Omni Directional Antenna ..................... 214
7002401: 11 dBi Omni Directional Antenna ................... 216
7002501: 16 dBi Outdoor Flat Panel Directional Antenna 218
7002601: 17 dBi Outdoor Flat Panel Directional Antenna 220
7002701: 22 dBi Outdoor High gain Flat Panel Directional
Antenna.......................................................................... 222
7002801: 8 dBi Indoor/Outdoor Patch Antenna.............. 224
7002901: 12 dBi 110 ° Outdoor Sectorial Antenna ......... 226
Warning: Systems that use fixed point-to-point (PTP) operations are excluded from the use of
point-to-multipoint systems, omni-directional applications and multiple co-located
intentional radiators transmitting the same information. You (the user and installer) bear
the responsibility for ensuring that a point-to-point system is used exclusively for those
PTP operations only (CFR 47 Part 15.247 b).
Notes: • All omni antennas should be mounted above the SkyWay bridge/router, near
the very top of the mast.
• Antennas are not shown to scale.
• Solectek’s antennas are all weather units and we recommend that a profes-
sional installer perform the installation.
• All SkyWay Series antenna are supplied with a standard 8 ft coaxial pigtail
(LMR400) to interface with the transceiver.ctions
