Radio Characteristics:
Frequency: 2.4 to 2.4835 GHz
Radio Channels: From 2.4 to 2.475 GHz @6 MHz intervals--11 channels
RF Coding: Direct Sequence Spread Spectrum (DSSS)
Bit Error Rate (BER): • 11 Mbps 1x10-8 @-83 dBm
• 5.5 Mbps - 1x10-8 @ -86 dBm
• 2 Mbps - 1x10-8 @ -90 dBm
RF Security Codes: 128 variations available
Radio License
Required:
No user license required. Certified for user installation and
unlicensed operation per FCC 15.247 and FCC 15.203.
Hardware:
Chassis Type: Single, sealed, mast-mounted unit. UL Outdoor certifica-
tions.
Chassis Specifications: 8.5” W x 14” L x 3.5” H (.21m W x .35m L x .08m H)
Chassis
Environmental:
-30C to +70C
Power Supply: Input: Autosensing 100-250 VAC / Output: +48 VDC
Power Consumption: .5 amps @ 48 VDC
Certifications: FCC Class A, UL Outdoor, Industrie Canada, ETSI
SkyWay to Antenna
Cable:
8 foot (2.4m) chassis-to-antenna cable supplied
SkyWay to Hub/
Router:
Standard cable available in lengths of 100 feet, 200 feet,
and 300 feet (30m, 60m, and 90m)
Antennas: Various types of FCC certified grid, flat panel, sectoral, and
omni-directional antennas are available from Solectek
depending on wireless link distance and application
requirements. Antennas sold separately.
Options: 100Base-FX Fiber, or country-specific RF power levels
(e.g., ETSI for Europe)
