User's Guide

Status Summary
168
Status Summary
Checking the Status Summary
The 2.6 Status Summary screen is useful when you want to check the global parame-
ters for all ports.
2.6 Status Summary
Field Name MIB (Incoming) MIB (Outgoing)
Port Number • 1 - Serial port
• 2 - Ethernet port
•3 - RF port
• 256 - 512 (base sub
ports)
The port number for this record.
Port Type
The type of port to which this row of statistics apply.
Address
The MAC address of this port.
2.6. Status Summary Record 1 of 3
Port Port Physical
Number Type Address Bridging IP
------ -------------------- ----------------- -------- --
1 Serial RS-422 00:00:00:00:00:00 No No
2 Ethernet 100Mbit 00:ba:d0:ba:be:00 No Yes
3 RF-DLC Base Port 00:00:c4:1c:91:45 No Yes
\ - return to menu . - commands TAB - next available field ENTER - edit
