Checking the Address Resolution Protocol Table
The Address Resolution Protocol (ARP) table contains the physical mapping of MAC to
IP addresses. Use this table to add static IP ARP entries. Press
.A to begin editing.
2.4.1.5 ARP Table
Field Name MIB (Incoming) MIB (Outgoing)
Port [ipNetToMediaIPIndex]
The IP port at which the IP address can be reached.
IP Address [ipNetToMediaNetAd-
dress]
The IP address.
MAC Address [ipNetToMediaPhysAd-
dress]
The physical or MAC address.
Ty p e [ipNetToMediaType] •STATIC
•DYNAMIC
•INVALID
Whether this entry is static or dynamic. Static values are user-entered, and dynamic
entries are learned from the network.
2.4.1.5. ARP Table Record 0 of 0
Port IP Address MAC Address Type
---- --------------- ----------------- ------
\ - return to menu . - commands TAB - next available field ENTER - edit
