Checking ICMP Activity
The 2.4.1.4 ICMP Status screen provides details on the type of ICMP datagrams that
are received and transmitted.
2.4.1.4 ICMP Status
In this screen, the Incoming column reflects the number of ICMP packets received by
the SkyWay, and the Outgoing column displays the number transmitted.
This screen is read-only.
Field Name MIB (Incoming) MIB (Outgoing)
Packets [icmpInMsgs] [icmpOutMsgs]
This is the total of all ICMP events (Incoming and Outgoing) listed in the rest of this
table, including errors.
Timestamp Requests [icmpInTimestamps] [icmpOutTimestamps]
The number of ICMP Timestamp request messages received.
Timestamp Replies [icmpInTimestampReps] [icmpOutTimestam-
pReps]
The number of ICMP Timestamp reply messages received.
ICMP-Specific Errors [icmpInErrors] [icmpOutErrors]
The number of ICMP messages which the entity received but determined as having
ICMP-specific errors (bad ICMP checksums, bad length, etc.)
2.4.1.4. ICMP Status
Incoming: Outgoing:
Packets : 0 0
Timestamp Requests : 0 0
Timestamp Replies : 0 0
ICMP-Specific Errors : 0 0
Destination Unreachable Errors : 0 0
Time Exceed Errors : 0 0
Address Mask Requests : 0 0
Address Mask Replies : 0 0
Echo Requests : 0 0
Echo Replies : 0 0
Source Quenches : 0 0
Router Redirects : 0 0
Parameter Problems : 0 0
\ - return to menu . - commands TAB - next available field ENTER - edi
