2.4.1.2 IP Address Table
Field Name MIB Comments
IP Port [ipAdEntIPIndex]
The physical port configured for IP routing. The Ethernet port is 2; the RF port is 3.
IP Address [ipAdEntAddr]
The IP address used to route packets on this port.
IP Mask [ipAdEntNetMask]
The IP Mask to be used for the IP address.
IP Broadcast [ipAdEntBcastAddr] 1=Yes; 2=No
Whether IP broadcasts can be sent or received on this port.
Reasm. Size [ipAdEntReasmMask] 65535
The maximum size a reassembled packet can reach.
2.4.1.2. IP Address Table Record 1 of 2
IP Port IP Address IP Mask IP Broadcast Reasm.Size
------- --------------- --------------- ------------ ----------
2 134.196.034.002 255.255.000.000 1 65535
3 196.028.145.069 255.255.255.000 1 65535
\ - return to menu . - commands TAB - next available field ENTER - edi
