IP Routing Screens
159
Fragmentation Failures [ipFragFails]
The number of IP datagrams that have been discarded because they could not be
fragmented as required.
Fragments Created [ipFragCreates]
The number of IP datagram fragments that have been generated as a result of frag-
mentation at this entity.
Packets Fragmented OK [ipFragOKs]
The number of IP datagrams that have been successfully fragmented at this entity.
Reassembly Requests [ipReasmReqds]
The number of IP fragments received which needed to be reassembled at this
entity.
Packets Reassembled OK [ipReasmOKs]
The number of IP packets successfully reassembled.
Reassembly Timeout [ipReasmTimeout]
The maximum number of seconds which received fragments are held while they
are awaiting reassembly at this entity.
Default Time to Live [ipDefaultTTL]
A number which together with the Route Cost determines how many hops a
packet is allowed to make before it is discarded. Each time a packet is forwarded,
the Default Time to Live (TTL) is decremented by the Route Cost. The packet can
continue to be forwarded as long as the Default TTL is not zero. This prevents
packets from being forwarded in an endless loop.
Routing [ipForwarding]
Indicates that this entity is acting as an IP gateway in that it is forwarding datagrams it
receives that are not addressed to it.
Field Name MIB Comments
