User's Guide

Bridging Screens
152
Checking Bridge Port Status
Use this screen 2.3.2 Bridge Port Status to monitor frame activity on the bridge port.
2.3.2 Bridge Port Status
Field Name MIB Comments
Port No. [swBridgePortStatusIn-
dex]
The physical port number or base sub port (sub station) number. On a sub station,
the bridge ports are 2 and 3. On a base station, the bridge ports are 2 and the sub
station numbers.
Max Info [swBridgePortStatusMax-
Info]
Maximum size of the information field that this port can transmit or receive.
In Frames [swBridgePortStatusIn-
Frames]
Frames, including bridge
management frames, are
added into the count only
if processed by the bridg-
ing function.
Total number of frames received on this port.
2.3.2. Bridge Port Status Record 1 of 1
Port Max In Out In MTU Exceeded
No. Info Frames Frames Discards Discards
---- ---- ------------- ------------- ------------- -------------
2 1492 0 0 0 0
\ - return to menu . - commands TAB - next available field ENTER - edi
