User's Guide

Bridging Screens
151
For more information about these configuration settings, see “1.3.1 Bridge Configura-
tion” on page 90
Bridge Max Age [dot1dStpBridgeMaxAge]
The value that all bridges use for Max Age when this bridge is acting as the root.
Bridge Hello Time [dot1dStpBridgeHelloTim
e]
The value that all bridges use for Hello Time when this bridge is acting as the root.
Bridge Forward Delay [dot1dStpBridgeForward
Delay]
The value that all bridges use for Forward Delay when this bridge is acting as the
root.
Forward Table Timeout [dot1dTpAgingTime]
The timeout period in seconds for aging out dynamically learned forwarding infor-
mation.
Time Since last Topology
Change
[dot1dStpTimeSinceTopol
ogyChange]
The time since the last time a topology change was detected by the bridge entity.
Topology Changes [dot1dStpTopologyChang
es]
The total number of topology changes detected by the bridge since the manage-
ment entity was last reset or initialized.
Field Name MIB Comments
