RF-DLC Screens
146
Checking the Polling Status
The following screen lists the sub stations and displays their IP addresses and the poll
list on which they are currently listed. For more information about polling, see “Polling
on page 67.
2.5.3 RF-DLC Sub Poll Status
Field Name MIB Comments
Sub Station Number
The sub station number, which corresponds to the base sub port number.
IP Address
The IP address of the sub station.
Polling Status Fast Poll
Slow Poll
Inactive Poll
The poll list on the base station where this sub station is currently listed.
2.5.3. RF-DLC Sub Poll Status Record 1 of 1
Sub Station IP Polling
Number Address Status
------- --------------- ------
256 204.212.131.068 Inactive Poll List
