RF-DLC Screens
145
XID TX [swRFDLCSub-
PortOutXID]
The number of Exchange station identification commands sent to the sub station.
XID REC [swRFDLCSubPortInXID]
The number of Exchange station identification responses received from the sub sta-
tion.
UA [swRFDLCSubPortUA]
The number of Unnumbered acknowledgement responses received from the sub
station.
DISC [swRFDLCSubPortDISC]
The number of Disconnect commands sent to the sub station.
RD [swRFDLCSubPortRD]
The number of Request disconnect reponses received from the sub station.
DM [swRFDLCSubPortDM]
The number of Disconnect mode responses received from the sub station.
Field Name MIB Comments
