Checking the Sub Port Status
You can access the 2.5.2 RF-DLC Sub Port Status screen on either the base station or
the sub station. On the base station, this screen shows the status of all the base sub
ports (sub station numbers). On the sub station, this screen shows the status of that
sub station.
2.5.2 RF-DLC Sub Port Status
Field Name MIB Comments
Port No. [swRFDLCSubPortIndex]
This is the physical RF port or sub station number.
SNRME [swRFDLCSubPortSN-
RME]
The number of Set normal response mode extended (SNRME) commands sent to
the sub station. A UA is the expected response.
FRMR [swRFDLCSubPortFRMR]
The number of Frame reject responses sent from the sub station when it receives
an invalid frame.
IFrames TX [swRFDLCSub-
PortOutIFrame]
The number of IFrames transmitted.
2.5.2. RF-DLC Sub Port Status Record 1 of 1
Prt SNRME FRMR IFrames RR State
No. TX REC TX REC
--- ---------- ---------- ---------- ---------- ---------- ---------- -----
3 4 0 655 127 120434 120654 NRM
REJ TX 0 UA 2
REJ REC 10 DISC 0
RNR TX 0 UI TX 0 XID TX 1 RD 0
RNR REC 0 UI REC 0 XID REC 1 DM 0
\ - return to menu . - commands TAB - next available field ENTER - edit
