RF-DLC Screens
142
UI TX [swRFDLCBasePortOu-
tUI]
The number of Unnumbered information commands sent to all sub stations.
UI REC [swRFDLCBasePortInUI]
The number of Unnumbered information responses received from all sub stations.
XID TX [swRFDLCBase-
PortOutXID]
The number of Exchange station identification commands sent to all sub stations.
XID REC [swRFDLCBasePort-
InXID]
The number of Exchange station identification responses received from all sub sta-
tions.
UA [swRFDLCBasePortUA]
The number of Unnumbered acknowledgement responses received from the sub
station.
DISC [swRFDLCBasePort-
DISC]
The number of Disconnect commands sent to all sub stations.
RD [swRFDLCBasePortRD]
The number of Request disconnect responses received from all sub stations.
DM [swRFDLCBasePortDM]
The number of Disconnect mode responses received from all sub stations.
Field Name MIB Comments
