RF-DLC Screens
141
SNRME [swRFDLCBasePortSN-
RME]
The number of Set Normal Response Mode Extended (SNRME) commands sent to
all sub stations. A UA is the expected response.
FRMR [swRFDLCBasePort-
FRMR]
The number of Frame reject responses sent from the sub station when it receives
an invalid frame.
IFrames TX [swRFDLCBase-
PortOutIFrame]
The number of IFrames transmitted.
IFrames REC [swRFDLCBasePortInI-
Frame]
The number of IFrames received.
RR - TX [swRFDLCBase-
PortOutRR]
The number of Receive ready commands sent to all sub stations.
RR - REC [swRFDLCBasePort-
INRR]
The number of Receive ready responses received from all sub stations.
REJ TX [swRFDLCBase-
PortOutREJ]
The number of Reject commands sent to all sub stations.
REJ REC [swRFDLCBasePortInREJ]
The number of Reject responses received from all sub stations.
RNR TX [swRFDLCBase-
PortOutRNR]
The number of Receive not ready commands sent to all sub stations.
RNR REC [swRFDLCBasePortIn-
RNR]
The number of Receive not ready responses received from all sub stations.
Field Name MIB Comments
