RF-DLC Screens
140
RF-DLC Screens
Use these screens to monitor the status of RF-DLC Base and Sub ports. They provide
information about frames sent and received, port states, events, actions, etc. The
screens in this section are all read-only.
Note The base station sends commands to the sub station and receives responses from the
sub station.
Checking RF-DLC Base Port Status
The 2.5.1 RF-DLC Base Port Status screen displays statistics that show the number of
frames transmitted or received as a response from all sub stations. On the base station,
this screen shows a summary of activity from all the sub stations. On sub stations, the
values all will be zero.
2.5.1 RF-DLC Base Port Status
Field Name MIB Comments
Port No. [swRFDLCBasePortIn-
dex]
3
This is the physical RF port.
2.5.1. RF-DLC Base Port Status Record 1 of 1
Prt SNRME FRMR IFrames RR
No. TX REC TX REC
--- ---------- ---------- ---------- ---------- ---------- ----------
3 4 0 127 655 120654 120434
REJ TX 10 UA 2
REJ REC 0 DISC 0
RNR TX 0 UI TX 0 XID TX 1 RD 0
RNR REC 0 UI REC 0 XID REC 1 DM 0
\ - return to menu . - commands TAB - next available field ENTER - edit
