User's Guide

Port Status and Control Screens
137
Checking the RF Port
Use the 2.2.4 RF Port Status screen to list RF ports and monitor link statistics. The
screen displays the information and statistics for a given port.
2.2.4 RF Port Status
Field Name MIB Comments
Port Number [swRFPortIndex] 3
RF physical port number.
Port Type [swRFPortType] •Base Port
•Sub Port
•Base Port Diag
•Sub Port Diag
The type of port (driver) this status is displaying.
Port Status [swRFPortStatus] • On-line
• Off-line
The operational status of the port.
RF data rate [swRFPortBW] •2 Mbs
• 5.5 Mbs
• 11 Mbs
The RF data rate for this port.
2.2.4. RF Port Status Record 1 of 1
Port Number : 3
Port Type : RF Base Port
Port Status : Online
RF data rate : 5.5 Mbps
RF Channel : 2414 Mhz
Bytes IN : 0 Bytes OUT : 2703
Frames IN : 749 Frames OUT : 901
Discards IN : 0 Discards OUT : 0
Digital Phase Lock Loop : 0
Frame Length Violation : 0
Non Octet Aligned Frame : 0
Abort Sequence : 0
CRC error : 0
Overrun : 0
Carrier Detect Lost : 0
Underrun : 0
CTS Lost : 0
\ - return to menu . - commands TAB - next available field ENTER - edit
