User's Guide

Port Status and Control Screens
134
Checking the Ethernet Port Status
From the 2.2.3 Ethernet Port Status menu, you can check how many times Ethernet
Port errors or conditions occurred, and the status of the Ethernet Transceiver.
2.2.3.1 Ethernet Port Status
Field Name MIB 2
Port Number [dot3StatsIndex]
The physical port number is 2.
Alignment Errors [dot3StatsAlignmentError
s]
The number of frames received on a particular interface that are not an integral
number of octets in length and do not pass the FCS check.
FCS Errors [dot3StatsFCSErrors]
The number of frames received on a particular interface that are an integral number
of octets in length but do not pass the FCS check.
Single Collision Frames [dot3StatsSingleCollisionF
rames]
The number of successfully transmitted frames on a particular interface for which
transmission is inhibited by exactly one collision
2.2.3.1. Ethernet Port Status Record 1 of 1
Port Number : 2
Alignment Errors : 0
FCS Errors : 0
Single Collisions : 0
Multiple Collisions : 0
SQE Test Errors : 0
Frames Deferred : 0
Late Collisions : 0
Excessive Collisions : 0
Internal MAC Transmit Errors : 0
Carrier Sense Lost : 0
Frames Too Long : 0
Internal MAC Receive Errors : 0
\ - return to menu . - commands TAB - next available field ENTER - edit
