Checking SNMP Status and Trap History
From the 2.1.2 Network Management Status menu, you can check how many times
SNMP errors occurred using the following two screens.
2.1.2.1 SNMP Status
This screen lists all the SNMP errors that may have occurred and the number of times
the error occurred since the last reset.
At the bottom of the screen, the fields list the number of incoming and outgoing SNMP
packets and traps.
2.1.2.1. SNMP Status
In Bad Version : 0
In Bad Community Name : 0
In Bad Community Use : 0
In Bad ASN : 0
In Read Only : 0
Out Too Bigs : 0
Out No Such Name : 0
Out Bad Values : 0
Out General Error : 0
Total Retrieved MIB Objects : 0
Total Altered MIB Objects : 0
In Get Requests : 0
In Get Next Requests : 0
In Set Requests : 0
Out Get Responses : 0
Authentication Traps : Enabled
Incoming: Outgoing:
Packets : 0 0
Traps : 0 0
