3.2 Ping Utility
The following table lists the field name, the MIB name, and field options with the
default setting, if any, in bold:
Field Name MIB
Settings (default in
bold)
Destination IP Address [swPingDestIPAddr]
The IP address of the unit you want to send an ICMP Echo Request to.
Ping Payload Size [swPingPacketSize] 64
6464
64
The ping packet size.
Number of Packets [swPingNumPackets] 0
The number of packets to be sent during the ping session or operation.
Reply Timeout [swPingReplyTimeout] 1
The number of seconds to wait before this ping session times out.
Delay Between Packets [swPingDelay] 0
The delay in milliseconds between each ping sent out during this ping session.
Ping Operation [swPingOperation] •Start Ping
•Abort Ping
Starts or stops the ping operation.
3.2. Ping Utility
Destination IP Address : 000.000.000.000
Ping Payload Size : 64
Number of Packets : 0
Reply Timeout : 1
Delay Between Packets : 0
Ping Operation : Start Ping
Ping Session Status : Idle
Packets Sent : 0
Correct Responses Received : 0
Incorrect Responses Received : 0
Number of Timed Out Packets : 0
Longest Round Trip Delay : 0
Shortest Round Trip Delay : 0
Average Round Trip Delay : 0
\ - return to menu . - commands TAB - next available field ENTER - edit
