Ping Utility
The Ping utility tests communications between units in a system that is already opera-
tional. Ping generates an ICMP Echo Request packet and expects to receive an ICMP
Echo Reply packet.
Te s t t o R u n [swRFSubTestToRun] • Burst Frame Ping Pong
Mode
• Continuous Burst
Receive
• Continuous Single
Frame Receive
• Single Frame Ping Pong
Mode
• Static Size Ping Pong
Mode
Note:
Note: Note:
Note: See “4.1 RF Base Radio Test” on page 105 for test descriptions.
Field Name MIB
Settings (default in
bold)
