User's Guide

IP Routing
95
Configuring the IP Ports
Before you begin you need to have the IP Address and the IP Mask for the unit you are
configuring.
1.4.2 IP Port Configuration
The following table lists the field name, the MIB name, and the default setting:
Field Name MIB
Settings (default in
bold)
Port Number [swIpPortIndex] 2
The port number for this IP configuration.
Proxy ARP [swIpPortProxyArp] •Enabled
• Disabled
Determines whether proxy Address Resolution Protocol (ARP) is enabled.
IP Address [swIpPortAddr]
This is the IP address for this IP port (configurable).
IP Mask [swIpPortMask]
This is the subnet mask.
1.4.2. IP Port Configuration Record 1 of 2
Port Number : 2
Proxy ARP : Enabled
IP Address : 134.196.034.001
IP Mask : 255.255.000.000
IP Encapsulation : Standard Ethernet
IP MTU : 1492
Arp Retry Timeout : 30
Arp Aging Timeout : 300
Arp Max Retries : 5
Configuration Status : Valid
\ - return to menu . - commands TAB - next available field ENTER - edit
