User's Guide

Bridging
91
Bridge Priority [dotIdStpPriority] 32768
This allows you to influence the choice of root bridge and designated bridge. A
lower numerical value means the bridge is closer to becoming the root. and thereby
change the topology of the spanning tree.
Bridge Max Age [dotIdStpBridgeMaxAge] 20
The amount of time in seconds the bridge waits before it discards configuration
BPDUs.
Bridge Hello Timeout [dotIdStpBridgeHello-
Time]
2
The amount of time in seconds before the bridge issues a configuration BPDU.
BPDU Forward Delay [dotIdStpBridgeForward-
Delay]
15
The amount of time a port waits before going into a forwarding state.
Multicast Address [swBridgeMulticastAddr]
The spanning tree multicast address contained in the configuration BPDU (mes-
sage). This is the MAC address of packets intended for a bridge.
Field Name MIB
Settings (default in
bold)
