Configuring the Ports
87
Selector Field: [swEtherTransCfgSelec-
tor]
•
••
• IEEE 802.3
IEEE 802.3IEEE 802.3
IEEE 802.3
• IEEE 902.9 ISLAN 16T
Modifiable only is Auto-negotiation is enabled. This is the IEEE Selector Field. Typical
users can accept the default of IEEE 802.3.
Record Type: [swEtherTransCfgType] •
••
• Valid
ValidValid
Valid
• Invalid
Indicates the status of this particular ethernet transceiver configuration. If valid, this
configuration is enabled. If marked as invalid, this record will be deleted and will not
exist after the next reset.
Field Name MIB
Settings (default in
bold)
