User's Guide

Configuring the Ports
85
Configuring the Ethernet Transceiver
1.2.2.2 Ethernet Transceiver Configuration
Field Name MIB
Settings (default in
bold)
Ethernet Port Number [swEtherTransCfgIndex] 2
The Ethernet port number is 2.
Interface Type [swEtherTransCfgInter-
face]
•
••
•Auto-Negotiation
Auto-NegotiationAuto-Negotiation
Auto-Negotiation
• 10BASE-T
• 100BASE-TX
• 100BASE-FX
Type of interface connected to the Ethernet port.
Duplex Mode [swEtherTransCfgDuplex] •
••
• Full Duplex
Full DuplexFull Duplex
Full Duplex
•Half Duplex
Duplex Mode for the Ethernet transceiver.
SQE (10Base-T) [swEtherTransCfgSQE] •Enabled
•
••
• Disabled
DisabledDisabled
Disabled
When SQE (heartbeat) function is enabled, the transceiver will assert COL output
for 5-15 BT after each packet. Valid only for 10Base-T.
1.2.2.2. Ethernet Transceiver Configuration Record 1 of 1
Ethernet Port Number : 2
Interface Type : Auto-Negotiation
Duplex Mode : Full Duplex
SQE (10Base-T) : Disabled
Jabber (10Base-T) : Enabled
Auto Negotiate : Enabled
Remote Fault : Disabled
Pause : Enabled
100BASE-TX full-duplex : Enabled
100BASE-TX : Enabled
10BASE-T full-duplex : Enabled
10BASE-T : Enabled
Selector Field : IEEE 802.3
Record type : Valid
\ - return to menu . - commands TAB - next available field ENTER -
