User's Guide

Configuring the Ports
83
Configuring the Ethernet Port
1.2.2.1 Ethernet Port Configuration
Field Name MIB
Settings (default in
bold)
Port Number [swEtherPortIndex] 2
The Ethernet port is 2.
Configuration Status [swEtherPortConfigSta-
tus]
• On-line
• Off-line
Determines whether the port comes up at initialization time. You must reset the unit
for changes to take affect.
MAC Address [swEtherPortPhysAd-
dress]
The MAC address of this Ethernet port.
Bridging Encap Type [swEtherPortBridgingEn-
capType]
• Ethernet II encap
• Ethernet 802.3 encap
Encapsulation used for bridging.
Port Type [swEtherPortPortType] Ethernet 802.3
This field is not configurable.
1.2.2.1. Ethernet Port Configuration Record 1 of 1
Port Number : 2
Configuration Status : On-line
MAC Address : 00:ba:d0:ba:be:00
Bridging Encap Type : Ethernet 802.3 encap
Port Type : Ethernet 802.3
Buffers : 1200
Transmit Buffers : 256
Receive Buffers : 512
Maximum Frame Size : 1518
Record Type : Valid
\ - return to menu . – commands TAB - next available field ENTER - edit
