Configuring the Base Sub Ports
If you have disabled ADP, you must manually configure the base sub ports on the base
station using the 1.2.3.1.3 RF Base Sub Port Configuration screen. If you have ADP
enabled, you do not need to configure base sub ports.
1.2.3.1.3 RF Base Sub Port Configuration
Note Ty p e .A to add a base sub port and to begin editing.
The following table lists the field name, MIB, and the default or field options with the
default setting in bold:
1.2.3.1.3 RF Base Sub Port Configuration Record 1 of 1
Sub Station Number :256
Configuration Status :On-line
Port Type :RF-DLC Base to Sub Port
Corresponding Substation RF Port
IP Address :000.000.000.000
Record Type :Valid
\ - return to menu . - commands TAB - next available field ENTER - edit
Field Name MIB
Settings (default in
bold)
Sub Station Number [swRFBaseSubPortIndex] 256
The sub station number for this Base to Sub station port.
Configuration Status [swRFBaseSubPortCon-
figStatus]
•
••
• On-line
On-lineOn-line
On-line
• Off-line
Determines if the port is enabled during initialization (On-line). Set to off-line to dis-
able the port.
Port Type [swRFBaseSubPortPort-
Ty p e ]
RF-DLC Base to Sub Port
This read-only field defines this port as a RF-DLC Base to Sub station port.
Corresponding Substation
RF Port IP Address
[swRFBaseSubPortSub-
RFIPAddr]
000.000.000.000
The IP address of the sub station.
