Configuring the Ports
79
The number of receive buffers.
Maximum Frame Size: [swRFSubPortMaxFrame-
Size]
3200
This read-only field sets the maximum frame size for each frame originating from
this port.
Sub Station Number [swRFSubPortStation-
Num]
0
Sub Station number for this sub station. If ADP is enabled, set this parameter to
zero.
Link Down Timeout
Interval
[swRFSubPortLinkTO] Seconds
The length of time this substation tries to link up to the base station.
Record Type [swRFSubPortType] • Valid
• Invalid
Indicates the status of this port configuration. If valid, this port configuration is
enabled. If marked as invalid, after the next reset or port cycle, this port will not exist
as a sub station port.
Field Name MIB
Settings (default in
bold)
