1.2.3.1.2 RF Sub Port Configuration
Note Ty p e .A to begin editing the screen.
Use this screen to set the sub station port parameters. The following table lists the field
name, MIB, and the default, or field options with the default in bold:
1.2.3.1.2 RF Sub Port Configuration Record 0 of 0
Port Number :3
Configuration Status :On-line
Port Type :RF-DLC Sub Port
Max Buffers :800
Transmit Buffers :240
Receive Buffers :180
Maximum Frame Size :3200
Sub Station Number :0
Link down Timeout Interval (1.5 msec) :320
Record Type :Valid
\ - return to menu . - commands TAB - next available field ENTER - edit
Field Name MIB
Settings (default in
bold)
Port Number: [swRFSubPortIndex] 3
The RF physical port number is 3.
Configuration Status: [swRFSubPortConfigSta-
tus]
•
••
• On-line
On-lineOn-line
On-line
• Off-line
Determines if the port is initialized when a reset occurs. Set Off-line to prevent the
port from initializing upon reset. Online initializes the port upon reset.
Port Type [swRFSubPortPortType] Sub Port
This read-only field defines this port as a sub station port.
Max Buffers: [swRFSubPortMaxBuffers] 800
The number of message buffers allocated to this sub station port.
Transmit Buffers: [swRFSubPortTransDesc] 338
The number of transmit buffers.
Receive Buffers: [swRFSubPortRecvDesc] 140
