User's Guide

Configuring the Ports
75
Configuration Status [swRFBasePortConfigSta-
tus
•
••
• Off-line
Off-lineOff-line
Off-line
• On-line
Determines if the port is initialized upon reset. Off-line prevents the port from initial-
izing upon reset.
Port Type [swRFBasePortPortType] RF-DLC Base Port
This is a read-only field that defines this port as a base port.
Max Buffers [swRFBasePortMax-
Buffers]
800
The number of message buffers allocated to this base port.
Transmit Buffers [swRFBasePortTrans-
Desc]
240
The number of transmit buffers.
Receive Buffers [swRFBasePortRecvDesc] 180
The number of receive buffers.
Maximum Frame Size [swRFBasePortMax-
FrameSize]
3200
This is a read-only field that sets the physical MTU, or largest frame that can be
transmitted from this port.
Slow Polling Timeout [swRFBasePortSlow-
PollTO]
15 seconds
The slow poll time out interval in seconds.
First Sub Station Number [swRFBasePortFirstSub-
Addr]
256
The first possible sub station number.
Last Sub Station Number [swRFBasePortLastSub-
Addr]
287
The last possible sub station number.
Automatic Discovery Pro-
tocol
[swRFBasePortADP] •
••
•Enabled
EnabledEnabled
Enabled
• Disabled
Determines if Automatic Discovery Protocol is running. If enabled, you must also
specify the ADP mode.
Field Name MIB
Settings (default in
bold)
