Charge/ Discharge Profile Programming Status

This screen is displayed only if Charge/ Discharge Profile Programming [Time-of-Use

(TOU)] is configured, and shows information about the TOUsettings for the site.

N a m e : x x x x

L a s t S y n c : < D a t e >

S o u r c e : < R e m o t e >

S e t U n t i l : < d a t e >

Name: The TOUprofile file name

Last Sync: Date when the time-of-use profile was loaded from the monitoring

platform

Source: the source from which the TOUprofile was uploaded:

Remote - Profile uploaded from the SolarEdge monitoring platform

Local - Profile uploaded from an SDcard

Set Until: The date until the current profiles applicable

Chapter 8: User Interface 95

StorEdge Solution with Backup MAN-01-00262-1.5
