Power Control Status
This screen is displayed only when Power Control is enabled (available from
communication board (CPU) firmware version 2.7xx/3.7xx and later).
P W R C T R L : R E M O T E
P W R L i m i t : 1 0 . 0 4 k W
C o s P h i :    0 . 9
P o w e r P r o d : 7 0 0 0 W

PWR CTRL: The power control status:
REMOTE - Communication with the RRCR or smart energy manager is
confirmed/validated.
LOCAL - The power is controlled locally (e.g. by a fixed limit), or this inverter limits
the PV power production to its relative portion of the feed-in power limit, as a
result of disconnected communication with the smart energy manager. If this
status appears, check the communication to the smart energy manager or the
communication to the meter.
PWR Limit: The inverter maximum output power set by one of the power limiting
options:
RRCR
Smart energy manager (Feed-in limitation)
P(f)
P(U)
Q(U)
Cos Phi: The ratio between active to reactive power
Power Prod: The power produced by the inverter
For more information, refer to the Power Control Application Note ,
available on the SolarEdge website at
http://www.solaredge.us/files/pdfs/application_note_power_control_
configuration.pdf.
Battery Status
This screen is displayed only when the battery is configured, and shows the battery
identification information, its charging status and power, and the operating mode.
