MID: The Master ID of the coordinator (master) ZigBee Plug-in. This field is shown
only in devices with router (slave) ZigBee cards, and after a successful ZigBee
association. If a ZigBee Plug-in is not connected, a No ZigBee message is displayed
instead of the MID field.
Cellular Status
If a cellular (CDMA)Plug-in is connected, this screen replaces the Server status screen:
S e r v e r : C e l l    < S _ O K >
S t a t u s :          < O K >
M N O : < X X X X X X >    S i g : 5
< E r r o r m e s s a g e >
Server: The method of communication to the SolarEdge monitoring platform.
Should display Cell.
Status: Displays OK if the inverter established a successful physical connection to
the Cellular Plug-in.
S_OK: The last communication to the SolarEdge monitoring platform was successful
(appears if the inverter is connected to the platform).
Sig: The signal strength, received from the Cellular Plug-in. A value between 0-5, (0
= no signal, 5 = excellent signal).
Error message per communication connection status failure
GSMStatus
If a GSM Plug-in is connected, this screen replaces the Server status screen:
S e r v e r : C e l l  < S _ O K >
S t a t u s :        < O K >
M N O : < x x x x x x x > S i g : 5
< E r r o r m e s s a g e >
Server: The method of communication to the SolarEdge monitoring platform.
Should display Cell.
Status: Displays OK if the inverter established a successful physical connection to
the modem.
S_OK: The last communication to the SolarEdge monitoring platform was successful
(appears if the inverter is connected to the platform). If S_OK is not displayed, refer
to Status Screens - Operational Mode on page 86.
MNO: The mobile network operator name
