If a meter (RGM) is connected to the inverter, the following status screen, showing the
power and energy readings, is displayed in addition to the above screen.
If the meter is set to Export +Import, there are two status screens, with the first line
displaying: "Export Meter" or "Import Meter". The following is an example of an export
meter status:
E x p o r t M e t e r
S t a t u s : < O K / E r r o r # >
P o w e r [ W ] : x x x x x . x
E n e r g y [ W h ] : x x x x x . x
Status: Displays OK if the meter is communicating with the communication board.
<Error message>: If there is a meter error, it is displayed in this line. Refer to
Troubleshooting on page 123.
Power (W): Depending on the meter type connected to the inverter, this line
displays the exported or imported power in Watts.
Energy (Wh): The total energy read by the meter, in Watt/hour. The value displayed
in this line depends on the meter type connected to the inverter and its location:
If a bidirectional meter is connected at the consumption point, this value is the
consumed energy.
If the meter is installed at the production connection point, this value is the energy
produced by the site.
If the meter is installed at the grid connection point, this value is the energy
exported to the grid.
If the inverter is connected to the SolarEdge server, this value will also be displayed in
the monitoring platform.
NOTE
This data is accumulated according to an internal real-time clock.
Telemetry Status
This screen displays the last power optimizer telemetry received. The display changes as
each power optimizer sends its telemetry.
In order to verify proper installation, the installer may view the Telemetry window for
some time in order to observe the power optimizers' report process.
