Installation Guide

Communication
1.
Select the Communication option to define and configure:
The communication option used by the inverter to communicate with the
SolarEdge monitoring platform
The communication option used to communicate between multiple SolarEdge
devices or other external non-SolarEdge devices, such as energy meters or
loggers.
2. Select Server to set which communication method is used to communicate between
devices and the monitoring platform. Refer to Setting Up Communication to the
Monitoring Platform on page 96 for a full description of these communication
options.
NOTE
The Server menu shows only the communication options installed in the
inverter.
The following shows a hierarchical tree of the menu options in the Communication
menu.
For detailed information about all the configuration options, refer to the
Communication Options Application Note , available on the SolarEdge
website at http://www.solaredge.us/files/pdfs/solaredge-communication_
options_application_note_v2_250_and_above.pdf.
Communication
(1)
,
(2)
:
S e r v e r < L A N >
L A N C o n f
R S 4 8 5 – 1 C o n f < S >
R S 4 8 5 – 2 C o n f < S >
Z i g B e e C o n f < S >
C e l l u l a r C o n f
G P I O C o n f < M T R >
Server:
(1)
When using the SolarEdge Cellular Plug-in with the provided SIM card, the Cellular Conf menu is unavailable.
(2)
When using the SolarEdge GSM products, RS232 Conf menu is unavailable.
StorEdge Solution with Backup MAN-01-00262-1.5
80 Configuration Menu Options
