DIPSwitch Setup

Verify that the DIPswitches on the system components are set as described in this

section, according to the system hardware configuration.

DIPSwitch Setup in Meter and Inverter

Termination and bias guidelines:

The last external meter in the RS485 chain should be terminated with 120 Ohm

(either internal or external).

Inverter communication board (

Figure 27

If a meter is installed: No termination - Left SW7 switch Down

If a meter is not installed: termination ON - Left SW7 switch Up (see also

Creating an RS485 Bus Connection

on page 104)

Figure 27: RS485 termination switch on the inverter communication board



StorEdge Solution with Backup MAN-01-00262-1.5

64 DIPSwitch Setup
