WARNING!

ELECTRICAL SHOCK HAZARD. Do not touch uninsulated wires when the

inverter cover is removed.

RISQUE D’ÉLECTROCUTION, ne touchez pas les fils non isolés lorsque le

couvercle de l'onduleur est retiré.

Activate the inverter:

a. Verify that the card S/N matches the inverter S/N.

b. Insert the card into the "CARD" slot on the communication board.

c. Turn ON the AC switch of the main circuit board.

d. LCD shows: Running Script...è Done!

Figure 18: Activation card

If LCDshows: Failed:

Turn AC OFF and ON (reset), and repeat the activation process.

Use the activation code that appears on the certification inverter label to

manually activate the inverter.

If the problem persists, contact SolarEdge Support.

NOTE

You can use the activation code that appears on the certification

inverter label to activate the inverter in case of a script error or a missing

activation card.



Chapter 6: Commissioning the Installation 47

StorEdge Solution with Backup MAN-01-00262-1.5
