Chapter 5: Meter Installation

The StorEdge solution requires connecting a meter for Smart Energy Management

applications, such as maximizing self-consumption. For backup power only, installing a

meter is not required. Refer to the table on page 16.

To install the SolarEdge meter, refer to the installation guide supplied with it:

http://www.solaredge.com/files/pdfs/solaredge-meter-installation-guide-na.pdf.

RS485 wiring specifications:

Cable type: Min. 3-wire shielded twisted pair (a shielded Ethernet cable

(CAT5/5E STP) may be used)

Wire cross-section area: 0.2-1 mm²/ 24-18 AWG (a CAT5 cable may be used)

Chapter 5: Meter Installation 43

StorEdge Solution with Backup MAN-01-00262-1.5
