StorEdge Connection Unit

Figure 10: StorEdge Connection Unit

The StorEdge Connection Unit includes:

DC safety switch: disconnects both the positive and negative conductors of the PV

and the positive and negative conductors of the battery.

Openings for conduit entry: Four openings are ready to use and have sealing

covers. Two openings are closed with drill guides. If required, open the drill guides

as described in

Opening Conduit Drill Guides

on page 136.

Internal AC Breaker and Bypass Switch

The following components are part of the StorEdge Connection Unit and may be

accessed for troubleshooting or maintenance by removing the internal cover.

StorEdge Solution with Backup MAN-01-00262-1.5

34 Inverter Interfaces
